제원 ℃ / mm / kg
모델 규격 재질 허용하중
(kg/4PCS)
L1 L H1 H B A 볼트/너트 패드
PF-8 40 57 10.5 11 Ø34 M8x1.25 Carbon Steel Pressed Steel 200
80 97
PF-10 60 81 13.5 8 Ø54 M10x1.5 300
100 121
PF-12 60 82 9 M12x1.75 500
90 112
120 142
150 172
PF-16
SPF-16
(Stainless Steel)		 50 79 17 11 Ø74 M16x2.0 Carbon Steel
Stainless Steel		 Pressed Steel
Stainless Steel		 800
80 109
100 129
130 159
150 179
180 209
200 229
PF-20
SPF-20
(Stainless Steel)		 100 131 14 M20x2.5 1,000
130 161
150 181
180 211
200 231
Material Surface Treatment
Carbon & Pressed Steel Ni Plated
Stainless Steel Polishing
