제원 ℃ / mm / kg
모델 규격 재질 허용하중
(kg/4PCS)
L1 L H1 H B A 볼트/너트 패드
PFA-10 60 85 17 8 Ø74 M10x1.5 Carbon Steel Pressed Steel 300
100 125
PFA-12 60 86 9 M12x1.75 500
90 116
120 146
150 176
PFA-16
SPFA-16
(Stainless Steel)		 50 78 11 M16x2.0 Carbon Steel
Stainless Steel		 Pressed Steel
Stainless Steel		 800
80 108
100 128
130 158
150 178
180 208
200 228
PFA-20
SPFA-20
(Stainless Steel)		 100 131 14 M20x2.5 1,000
130 161
150 181
180 211
200 231
Material Surface Treatment
Carbon & Pressed Steel Ni Plated
Stainless Steel Polishing
